It is real time & day based timer used to control any electrical device for the set time. It has 25 ON & OFF programmable time slots to switch ON & OFF.
Product Description:
Product Description:
Power ON/OFF switch: This switch is provided at the bottom of the device to switch ON or switch OFF the controller unit.
Alpha numerical 2x16 LCD display:
Home Screen: It will display the current date and day on the first line. It shows the current time and status on the second line
Status in the LCD: It includes Auto / Manual, Relay ON / OFF.
Menus
Set Date / Time: It helps to set the current date, month, year, hours, minutes and day.
Set ON & OFF time: It helps to set the ON & OFF time slots with day
Mode: It helps to select the AUTO / MANUAL operation. In AUTO mode, the timer works based on the set time. In MANUAL mode, NEXT and UP keys are used for switching ON /OFF operation
Change Password: It helps to change / update the current password.
Input Keys
1. SET key:It is used for entering the menu and to save the settings.
2. NEXT key: It is used for moving to the NEXT options like Menu, Successive Locations.
3. UP key: Used to set the values in date, time, password.
Salient Features
25 times switch ON & OFF programmable slots.
Real Time & Day based sequential ON & OFF.
Lithium Battery for Memory backup.
With Daily weekly and impulse program.
Auto/Manual mode options
Password Protected Access.
Alpha numerical 2x16 LCD display is provided.
3 input keys for easy programming.
Supports Wide input power supply AC 230 / 440 V.
Long Life
Easy to install
Suitable for Any Elecrical device
No Electric Shock
Advanced Embedded Technology
12 Months Warranty
Applications
Street Lights / Garden Light / Factory Light / Stair case Light Switching
